Product Features
● Low insertion loss and minimal signal loss.
● Designed specifically for troubleshooting network failure nodes
● High density splicing saves space and improves the overall efficiency of fiber optic connections.
● Stable operation within a wide temperature range of -40 ° C to 85 ° C, suitable for working requirements in different environments.
The design of a 12 core MPO/MTP connector enables high-density configuration of fiber optic connections, suitable for large-scale fiber optic cabling, saving space and improving system connection efficiency. This module is widely used in data centers, fiber optic communication, network equipment testing and other fields, and can effectively perform loop testing of optical signals to ensure the stability and reliability of fiber optic links. The design of the module takes into account the requirements of high-density connections and low insertion loss, providing an efficient and reliable solution.
Specifications
| Type | Female | Connector Type | MPO/MTP (supports single-mode or multi-mode) |
| Insertion Loss |
Single mode:< 1.2dB Multimode:< 0.8dB |
Fiber Count | 1x2, 2x2, 1x4 (customized according to requirements) |
| Return Loss | > 50dB | Working Wavelength | Single mode: 1310nm, 1550nm； Multimode: 850nm, 1310nm |
| Maximum transmission distance | Single mode: 2km; Multi mode: 300m | Working Temperature |
0~70° |
